Waterproof Membrane Panel Switch With Multi Buttons For Sports Equipment

Name: Waterproof Membrane Panel Switch With Multi Buttons For Sports Equipment
Brand: Zhongshan Membrane Switch
Price: 1 USD

Brand Name : Zhongshan Membrane Switch

Model Number : ZS-17

Certification : RoHS,ISO9001:2000

Place of Origin : Jiangsu, China (Mainland)

MOQ : 100pieces

Price : negotiation

Payment Terms : 30% deposit the 70% balance after shipment, or full payment after air transpotation

Supply Ability : 50000pieces per week

Delivery Time : with 7 working days after payment

Packaging Details : paper carton( outer) and plastic bubble bag (inner).Or per your needs.Special requirement accepted.

Life expectancy : Tactle 100million

Spring Time : ≤ 6ms

operating voltage : ≤ 35VDC

Switch Stroke : Flat 0.1~0.5mm

size : 120mm*55mm

material : PET

Contact Now

Printing 2 colors on overlay button / ZS-17 Application on Sports Equipment / such as Running machines

Waterproof Metal Dome Membrane switch Keyboard with Foil

1, operating voltage:

≤ 35VDC

2, working current:

≤ 100mA

3, Contact resistance:

0.5 ~ 5Ω

4, Insulation resistance:

≥ 100MΩ (100VDC)

5.Spring Time

≤ 6ms

6.Switch Stroke

Flat 0.1~0.5mm

Tactile 0.6~1.5mm

7.Operation Force

Flat 57g~286g

Tactile 170g~398g

8.Operation Temperature

-20℃~ +80 ℃

9.Storage Temperature

-40 ℃ ~ +85 ℃ temperature of 95% ± 5%

10, atmospheric pressure:

86 ~ 106kDa

11.Life expectancy

Flat 500Million-1000Million

Tactle 100million

Waterproof Membrane Panel Switch With Multi Buttons For Sports Equipment

Features:

1. Material: PET/PC with different thickness and finish

2. Button effect: embossing + metal domes respectively for good tactility and perfect

feedbacks.

Also we can offer the other options: a. embossing, no metal domes;

b. metal domes, no embossing

c. no embossing, no metal domes (flat type)

3. LEDs can be embedded;

4. LCD clear window can be made.

5. Colors for graphics are matched with Pantone No., Bi-color leds are also available.

Packaging
